| Layer count | 1-40 layers | |||
|---|---|---|---|---|
| Assembly Type | Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT) | |||
| Minimum Component Size | 01005 or 0201 (Imperial) / 0402 or 0603 (Metric) | |||
| Maximum Component Size | 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm) | |||
| Component Package Types | BGA, QFN, QFP, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, etc. | |||
| Minimum Pad Pitch | 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA | |||
| Minimum Trace Width | 0.10 mm (4 mil) | |||
| Minimum Trace Spacing | 0.10 mm (4 mil) | |||
| Minimum Drill Size | 0.15 mm (6 mil) | |||
| Maximum Board Size | 18 in x 24 in (457 mm x 610 mm) | |||
| Maximum Board Thickness | 0.062 in (1.6 mm) to 0.125 in (3.2 mm) | |||
| Board Material | FR-4, High-Tg FR-4, Aluminum, High Frequency, Flexible(FPC), Rigid-Flex, Rogers, etc. | |||
| Surface Finish | HASL, Immersion Gold, Gold Finger, OSP, Immersion Silver, etc. | |||
| Solder Paste Type | Leaded or Lead-Free | |||
| Assembly Process | Reflow Soldering, Wave Soldering, Hand Soldering | |||
| Inspection Methods | Automated Optical Inspection (AOI), X-ray, Visual Inspection | |||
| Testing Methods | In-Circuit Test (ICT), Functional Test (FCT), | |||
| Flying probe test | ||||
| Design for Manufacturing (DFM) | DFM Analysis and Feedback | |||
| Turnaround Time | Prototype: 24 hours to 7 days, Production: 10 days to 4 weeks | |||
| PCB Assembly Standards | ISO9001:2015;ISO13485:2016;ROHS,UL 94v0, IPC-600G classll and IPC-6012B classll standard |
Green Solar Panels
Layer count: 1-40 layers;
Assembly Type: Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT);
PCB Assembly Standards: ISO9001:2015;ISO13485:2016;ROHS,UL 94v0, IPC-600G classll and IPC-6012B classll standard;
